| Place of Origin: | CHINA |
|---|---|
| Brand Name: | TYF |
| Certification: | CE UL CB |
| Model Number: | PCBA |
| Minimum Order Quantity: | Negotiation |
| Price: | Negotiable |
| Packaging Details: | carton |
| Delivery Time: | 10 workdays |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100000 PCS/MONTH |
| Brand: | TYF | Copper Thickness: | 0.3-3oz |
|---|---|---|---|
| Base Material: | FR4, Aluminum, FPC | Surface Finishing: | HASL, OSP, Lead Free |
| Services: | One-stop Services | Max Board Size: | 760mm*600mm |
| Layer: | 1-26layers | Certificate:: | ISO9001/IATF16949/ISO13485 |
| Highlight: | printed circuit assembly,electronic circuit board assembly |
||
Shenzhen Professinal Pcba manufacturer printed circuit board led pcb assembly
1. Details:
Item name: SMT Assembly PCBA PCBA
Place of Origin: ShenZhen, China
Model: TYF PCBA
MOQ: 1000 piece
2. PCB Design & Layout
» Excellent Expertise in design tools: Allegro, Pads, and Mentor Expedition.
» High density SMT designs (BGA, uBGA, PCI, PCIE, CPCI…)
» Flex PCB designs of all sorts
» Complete assembly drawings
» In-Circuit Test data generation (ICT)
» Drill, panel and cutout drawings designed
» Professional fabrication documents created
» High-speed, multi-layer digital PCB designs- Bus routing, differential pairs, matched lengths; Fast PCB design in 2-3 days.
» Concentrate on the PCB design Wi-Fi Module, BLE Module, GPS Tracking application.RF Modules,Medical-Care devices,LED PCB Boards.
» We come up with the design as per customer requirement,and take care for the RAW material cost at the outset of design.
» Full control for the PCB design, from requirement, Schematic, PCB Layout, SI/PI/EMI inspection, we will locate the design issues in the inspection processing.
| PCB layer | 1, 2, 4 or 6, up to 18 layers | |||||||
| Board shape | Rectangular, round, slots, cutouts, complex, irregular | |||||||
| Board type | Rigid, flexible, rigid-flexible | |||||||
| Board material | FR-4 glass epoxy, FR4 High Tg, RoHS compliant; Aluminum, Rogers, etc. | |||||||
| Board cutting | Shear, V-score, tab-routed | |||||||
| Board thickness | 0.2 ~ 4.0 mm (±10%), Flex board: 0.01 ~ 0.25″ (±10%) | |||||||
| Copper weight | 1.0, 1.5, 2.0 Oz (tolerance ±0.25 oz) | |||||||
| Solder mask | Double-sided green LPI, Also support red, white, yellow, blue, black | |||||||
| Silk screen | Double-sided or single-sided in white,yellow, black, or negative | |||||||
| Silk screen min. line width | 0.006″ or 0.15mm | |||||||
| Max board dimension | 20 inch *20 inch or 500mm*500mm | |||||||
| Min. trace/gap | 0.10mm, or 4 mils | |||||||
| Min. drill hole diameter | 0.01”, 0.25mm, or 10 mils | |||||||
| Surface finish | HASL, Nickle, Imm Gold, Imm Tin, Imm Silver, OSP etc. | |||||||
| Min.slot width | 0.12”, 3.0 mm, or 120 mils | |||||||
| V-score depth | 20-25% of board thickness | |||||||
| Plated through holes | Yes | |||||||
| Design file format | Gerber RS274X, 274D, Eagle and AutoCAD’s, DXF, DWG, Protel 99se | |||||||
TYF Opto. LED modules products, packed in plastic Tray, according to different size, XX PCs each plastic Tray, as shown in the following. products without plastic box packed in bubble bags, in order to prevent the outside pressure, choose different bubble bag, according to the product size in each pack of XX products, packaged product will be stored in the form of carton and sealed, as shown in the following.
1) xx PCS LED module per Tray 4) Box information & packing
2)Tray stack and taping, XX LED module
trays and additional 1 dummy trays each up of
box. Add silica gel (1 each) on top of the tray
3) Sealing packing
